BAV99 1 Pair Series General Purpose Rectifier Diode Array Connection Standard

Brand Name : NXP

Model Number : BAV99

Place of Origin : CHINA

MOQ : 3000 PCS

Price : Negotiation

Payment Terms : T/T, Western Union ， ESCROW

Supply Ability : 300000PCS

Delivery Time : STOCK

Packaging Details : 3000PCS/REEL

Categories : Diodes - Rectifiers - Arrays

Voltage - DC Reverse (Vr) (Max) : 70V

Current - Average Rectified (Io) (per Diode) : 200mA

Voltage - Forward (Vf) (Max) @ If : 1.25V @ 150mA

Speed : Small Signal =< 200mA (Io), Any Speed

Reverse Recovery Time (trr) : 6ns

Current - Reverse Leakage @ Vr : 2.5µA @ 70V

Operating Temperature - Junction : -55°C ~ 150°C

Contact Now

BAV99 High-speed double diode Diode Array 1 Pair Series Connection Standard 70V 200mA Surface Mount

FEATURES

• Small plastic SMD package

• High switching speed: max. 4 ns

• Continuous reverse voltage:

max. 75 V

• Repetitive peak reverse voltage:

max. 85 V

• Repetitive peak forward current:

max. 450 mA.

APPLICATIONS

• High-speed switching in thick and

thin-film circuits

DESCRIPTION

The BAV99 consists of two

high-speed switching diodes

connected in series, fabricated in

planar technology, and encapsulated

in the small SOT23 plastic SMD

package

Product Attributes	Select All
Categories	Discrete Semiconductor Products
	Diodes - Rectifiers - Arrays
Manufacturer	ON Semiconductor
Series	-
Packaging	Tape & Reel (TR)
Part Status	Obsolete
Diode Configuration	1 Pair Series Connection
Diode Type	Standard
Voltage - DC Reverse (Vr) (Max)	70V
Current - Average Rectified (Io) (per Diode)	200mA
Voltage - Forward (Vf) (Max) @ If	1.25V @ 150mA
Speed	Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr)	6ns
Current - Reverse Leakage @ Vr	2.5µA @ 70V
Operating Temperature - Junction	-55°C ~ 150°C
Mounting Type	Surface Mount
Package / Case	TO-236-3, SC-59, SOT-23-3
Supplier Device Package	SOT-23-3 (TO-236)
